Before you start recording using the CD-RW900SL, make
sure that you understand the following key points:
Once you have recorded on a CD-R disc, the data
cannot be erased from it.
•
You can add tracks to an unfinalized recordable disc.
Once finalized, a CD-R disc is “fixed” and behaves in
the same way as a pre-recorded disc. Finalized CD-RW
discs, however, can be erased, refreshed and re-recorded.
•
Input monitoring
When the unit is in record ready, or record mode, the input
signal is output from the
OUT
jacks (digital and analog),
allowing you to hear the input signal.
Press the
RECORD
key on the front panel or the remote
control when a recordable disc is not inserted.
The word
Monitor
appears on the display to show that the
output signal is an echo of the input signal(s).
Exit the monitor mode by using the
STOP
key.
Frequency conversion
The sampling frequency for CDs is 44.1 kHz. The
CD-RW900SL will always record (and play back) CDs at
this frequency.
However, if recording through a digital connection (coaxial
or optical) and the source has been recorded at a frequency
other than 44.1 kHz, or is being played back at a non-stan-
dard speed using a varispeed unit (more than 1% away
from the standard), the CD-RW900SL’s internal frequency
converter: SRC (Sampling Rate Convertor) will automati-
cally convert the incoming frequency to 44.1 kHz.
To enable the SRC
Press the
MENU
key and select the SRC? option in the
REC sub-menu (see “Operation basics” on page 15). Rotate
the
MULTI JOG
dial to select
ON
. Press the
MENU
key or
push the
MULTI JOG
dial to enter.
NOTE
When the SRC function is off, and a digital signal is
received, the display shows the REC indicator flashing
while recording or when in recording standby mode.
The digital signals other than 44.1kHz cannot be
recorded when SRC is off. The error message
Not
Fs44.1k!
will appear on the display.
Input selection
To select the input to be recorded, press the
INPUT
SELECT
key on the main unit.
Repeated presses of the key cycle through the following
options:
ANALOG
Analog
OPTICAL
Optical digital in
COAXIAL
Coaxial digital in
In the case of either the coaxial or optical inputs being
selected, the indicator
COAXIAL
or
OPTICAL
lights up.
If the analog signal is selected, the
ANALOG
indicator lights
on the right of the screen.
Analog recording level:
The level of the analog signals received at the
ANALOG IN
jacks are controlled with the
INPUT
controls.
When recording analog signals, set the digital volume to
0 dB.
Digital recording level:
The level of the digital signal may be controlled using the
digital volume menu, as described below.
1. Call up the VOLUME option in the REC sub-menu
(see “Operation basics” on page 15).
Push the
MULTI JOG
dial to enter the function on.
2. Rotate the
MULTI JOG
dial to adjust the input
volume between -54dB and +18 dB (relative to the
original input level).
There is also a
-‹
setting which represents a complete
signal cut. The display shows
Vol> ---dB
for
the
-‹
setting.
3. Press the
MENU
key or push the
MULTI JOG
dial to
enter the setting and return to normal mode.
