Title:
Southern States 38 kV–170 kV
CapSwitcher
®
Vertical Interrupter Style Capacitor Switcher
Product Specification
Guide
Page 2 of 10
Publication No.: PSG-807-031109
1.0 SCOPE
This specification covers the design, manufacture, and testing of three pole, gang
operated vertical interrupter outdoor capacitor switchers available with or without
integrated transient over-voltage control and inrush current mitigation.
2.0 STANDARDS
All outdoor capacitor switchers shall be designed, manufactured, assembled, and tested
in accordance with the latest applicable ANSI, NEMA, and ASTM standards and
guidelines. If there are any conflicts between the ANSI, NEMA, or ASTM standards and
this specification the specification shall govern.
3.0 DESIGN REQUIREMENTS
3.01 Service Conditions
The capacitor switcher shall be suitable for outdoor installation in electric power
substations under the following conditions:
3.01.01 Temperature
The capacitor switcher shall perform in an ambient temperature range of
-40
o
C through +50
o
C.
3.01.02 Altitude
The capacitor switcher shall perform at elevations up to 3,300 feet.
3.01.03 Seismic
The capacitor switcher shall be capable of withstanding seismic loading
of 0.2 g ground acceleration in any direction when installed on the
manufacturer’s furnished support structure and anchor bolts and with
flexible connections to the terminal pads. The device shall perform its
specified functions during and after the seismic event.
3.01.04 Wind Loading
The capacitor switcher shall be capable of withstanding wind loads up to
90 mph without loss of function.
3.01.05 Additional Requirements
If any site-specific service conditions not covered in sections 3.01.01
through 3.01.04 exist (e.g. extreme cold temperature installation,
corrosive environment, high altitude installation, etc.) they will be defined
in the quotation request.
3.02 Ratings
3.02.01 General Specifications
