-9-
Main Frame / 本體組裝
Bag C+D
HMC2-4B
內六角螺絲,M2x4
SOCKET SCREW,M2x4
No.
1
2
3
Qty Material No. Description 名稱 No.
4
5
Qty Material No. Description 名稱
(4)
(2)
(1)
(3)
(3)
(5)
(2)
(1)
Completed View
組裝完成
Left Frame / 左側板
Right Frame / 右側板
Completed View
組裝完成
Apply threadlocker
使用螺絲防鬆膠
BK2255
HMC2-4B
BK2551 BV2238
BV2237 機身側板
內六角螺絲,M2x4
橡膠墊圈
升降舵墊片座組(左)
升降舵墊片座組(右)
ELEVATOR WASHER MOUNT SET(L)
ELEVATOR WASHER MOUNT SET(R) SIDE FRAME
SOCKET SCREW,M2x4
RUBBER GROMMETS 2
4
4 1
1
(3)
(3)
Must be purchased separately
改裝品需另購
