Thunder Tiger Titan X50 EF - Manual (Page 12)

-11-
BK0023
BK0084
BK2514
HME3-3B
HME3-8B
BK2571
BK0649-1
BK2515
HMC3-10B BK2261
BK0064T
BK0065
HME4-5B
HMC3-14B
BK2258
BK2274
BK2253
HNX3-12B 升降舵連接座
固定銷,D2x22.8
金屬升降舵控制臂
無頭內六角螺絲,M3x3
無頭內六角螺絲,M3x8
無平衡翼升降舵推拉桿, 4757
內六角連接頭螺絲(A)
控制臂軸環,d3xD5xW4.2
內六角螺絲,M3x10
腳架
底座圓管
圓管塞
無頭內六角螺絲,M4x5
內六角螺絲,M3x14
底盤
電池座
六角支柱
半圓頭內六角自攻螺絲
ELEVATOR CONTROL ARM LINK
PIN,D2x22.8
METAL ELEVATOR CONTROL ARM
SET SCREW.M3x3
SET SCREW,M3x8
FL ELEVATOR LEVER ROD, 4757
LINKAGE BALL(A)
COLLAR,d3xD5xW4.2
SOCKET SCREW,M3x10 LANDING SKID
SKID PIPE
SKID PIPE END CAP
SET SCREW,M4x5
SOCKET SCREW,M3x14
BOTTOM FRAME
BATTERY TRAY
FRAME SPACER
S.B.H SELF TAPPING SCREW 1
1
1
1
1
1
2
1
3
2
2
4
4
4
1
1
1
6
Landing Skid / 腳架組組裝
Bag E
HME3-3B
SET SCREW.M3x3
無頭內六角螺絲,M3x3
HME4-5B
SET SCREW,M4x5
無頭內六角螺絲,M4x5
HME3-8B
SET SCREW,M3x8
無頭內六角螺絲,M3x8
BK0649-1
LINKAGE BALL(A)
內六角連接頭螺絲(A)
BK2515
COLLAR,d3xD5xW4.2
控制臂軸環,d3xD5xW4.2
HMC3-10B
SOCKET SCREW,M3x10
內六角螺絲,M3x10
Apply threadlocker
使用螺絲防鬆膠
HMC3-14B
SOCKET SCREW,M3x14
內六角螺絲,M3x14
The larger hole goes toward
the swashplate.
較大孔面朝十字盤
HNX3-12B
S.B.H SELF TAPPING SCREW
半圓頭內六角自攻螺絲
(16)
(18)
(9)
(18)
(18)
(18)
(9)
(17)
(15)
(18) (18)
No.
1
2
3
4
5
6
7
8
9
Qty Material No. Description 名稱 No.
10
11
12
13
14
15
16
17
18
Qty Material No. Description 名稱
Completed View
組裝完成
(3)
(9)
(7)
(13)
(13)
(11)
(12)
(12)
(12)
(12)
(13)
(13)
(10)
(10)
(14)
(14)
(14)
(5)
(1)
(2)
(8)
(11)
(6)
(4)
Secure all screws shown on this page with a drop of thredlocker except the screws #13, 14 & 18.
除螺絲＃13, 14及18之外，本頁顯示之螺絲請使用適量防鬆膠鎖固。
