NS 830030P ROOF PANEL 2
12 849055P ROOF PANEL 2 (AFTER 0104MXH06)
13 848403P ROOF PANEL - REAR ISUZU
NS 101239P ROOF PANEL - REAR CAT
14 848610P ROOF PANEL - CENTER ISUZU
NS 830025P ROOF PANEL - FRONT
15 849054P ROOF PANEL - FRONT (AFTER 0104MXH06)
16 848282P SIDE DOOR ASSEMBLY - RIGHT
17 800229P SIDEPANEL - RIGHT REAR ISUZU
NS 101237P SIDEPANEL - RIGHT REAR CAT
18 830075P SIDE REAR PANEL - RIGHT
19 830060P SIDE FRONT PANEL - RIGHT
NS 830070P SIDE TOP PANEL - RIGHT
20 849056P SIDE TOP PANEL - RIGHT (AFTER 0104MXH06)
21 848383P SIDE BOTTOM PANEL - RIGHT
22 830130P REAR BUMPER
NS 466084P REAR BUMPER SPACER, 2 REQ’D
23 650129 TAILLIGHT, 2 REQ’D
NS 849053 TAILLIGHT/INTERLOCK WIRE HARNESS
24 330037 REFLECTOR, RED (2 REQUIRED)
25 101236 6” X 18” CHIMNEY (stainless steel)
26 848001 CHIMNEY RAIN CAP (stainless steel)
NS 840090 CHIMNEY VENT GRAB
27 330045 DOOR LATCH ASSEMBLY (INTERCHANGEABLE)
28 848283P SIDE DOOR ASSEMBLY - LEFT (19 1/2” H)
29 800230P SIDE PANEL - LEFT REAR ISUZU
NS 848412 MANUAL STORAGE BOX
30 830091P SIDE BOTTOM PANEL - LEFT
31 830086P DOOR FILLER - LEFT
32 849057P TOP HEADER - LEFT (AFTER 0104MXH06)
NS 830081 TOP HEADER - LEFT
33 848284P REAR DOOR ASSEMBLY
34 800231P AIR INTAKE COVER ISUZU
35 330041 DOOR STOP BUMPER
36 330011 JACK SIDE CRANK
37 848810P FRONT ACCESS PANEL (AFTER 0001MXH07)
NS 848162P FRONT ACCESS PANEL (0001MXH06 THRU 0216MXH06)
38 830006A WHEEL AND TIRE ASSY 15” X 6” 6-HOLE
39 848328 OUTER FENDER
NS 830006 WHEEL ONLY 15” X 6” 6-HOLE
NS 830004 TIRE ONLY ST225/75R15BD
NS 849053 WIRING HARNESS
TRAILER ASSEMBLY PARTS AND ACCESSORIES
A-2B
REF# PART# DESCRIPTION
LEGEND: NS = Not Shown
** = Purchase Locally
