106
"JOB FUNCTIONS" - F6 ALIGN
16.6 F6 Align
Moves the closest reference track, re-aligning it to the position of the machine.
This function is useful when you need to re-align the machine, whilst continuing to drive in the same
direction (for example, for corn, sugar cane).

1

2
Fig. 361
1 In the guidance screen, press Func .
2 Press F6 to align with the current position.
The closest reference track (
A
in Fig. 361) moves and becomes aligned with the center of the tractor: all other reference tracks move
accordingly. After the alignment, the deviation value >2.0> (
B
) becomes 0.0 .
Fig. 362
Once this function has been
used, it is not possible to restore
the original reference track.
B B
A A
Par.
7.4
Exit the function or
data change Confirm access
or data change Scroll
(LEFT / RIGHT)
Delete
selected
character Increase /
decrease
value
Scroll
(UP / DOWN)
Enter
selected
character
