53
CopperHead 3400
User Guide
Diagram # Description
9 Time Code In
BNC Connector – Standard time code signal sent to camera – typically
originating from “house” time code generator feed available to Base Station.
On remote productions the primary camera may be used to originate the
system time code feed (signal would return to base station via connector 8
and then be distributed to other cameras through the associated
Copperhead Base Stations.
10 Time Code Out
BNC Connector – Standard time code signal originating from the camera.
This time code can be used to reference the local camera time code for
proper operations and may also be used as a source for production wide
time code distribution.
11 Ethernet Connector – 10Bt/100Bt capable
Designed to carry IP traffic data between the Base Station and the Camera
Unit. A laptop PC or other device such as a Wireless Access Point can be
connected to the Production Environment IP network.
12 VBS Out
BNC Connector -Typically used for SD Monitoring Video return from the
Camera.
13 VBS In
BNC Connector – Typically used to send SD return video to the camera – an
example is monitor out from the Production Switcher.
14 SDI Out 1 & 2 (this carries the HD feed from the camera)
BNC Connectors – Two identical video feeds from the camera – typically one
may be used for local HD monitoring and one is fed to the Production
Switcher environment.
15 SDI In
BNC Connector – Typically used to send HD return video to the camera – an
example is program out from the Production Switcher.
16 SDI Out A & B (this carries the dual 3D/Dual-Link signals from the camera)
BNC Connectors
17 Audio In- Multi-Pin Connector
DB25 – 25 pin Connector follows the Tascam TDIF standard. The CopperHead
3400 Transceiver System accommodates up to two Audio Channels at Line
Level.
This connector handles return audio to the Camera location as well as
intercom Program Audio. See
Multi-Pin Connectors: Suggested Wiring on
page 92.
18 Audio Out- Multi-Pin Connector
DB25 – 25 pin Connector follows the Tascam TDIF standard. The CopperHead
3400 Transceiver System accommodates up to two Audio Channels at Line
Level. This connector handles Program audio from the Camera location. See
Multi-Pin Connectors: Suggested Wiring on page 92 for sample wiring.
