75
Specifications
Video, Digital (bi-directional)
Interface...................................................................................................... SMPTE 259M, 292M
Data Rate ............................................................................................. 270 Mb/s or 1.5 Gbits/s
Video, Digital (4K-3G Cam-to-Base)
Interface.............................................................. SMPTE 310M, 259M, 292M, 297M, 424M
Data Rate ................................................................................................. 19.4 Mb/s to 3.0 Gb/s
Video, Digital (all)
Input Level. ...........................................................................................800 mV (peak to peak)
Input/output Impedance........................................................................................... 75 Ohms
Output Impedance. ..................................................................................................... 75 Ohms
Bit-Error Rate (@ -22 dBm) ................................................................................................ 10-12
Jitter (pathological data)............................................................................................... < 0.2 UI
Rise/Fall Times ................................................................................................................ < 270 ps
Video, Analog (bi-directional)
Interface.......................................................................................................... RS170, NTSC, PAL
Frequency Response
30 Hz-4.2 MHz............................................................................................................±0.15 dB
8MHz. ................................................................................................................................... -3 dB
Video Signal to Noise Ratio.......................................................................................... ≥ 72 dB
Differential Gain .................................................................................................................... < 2%
Differential Phase ....................................................................................................................< 1°
Ethernet
Data Support............................................................................................... 10BaseT/100BaseT
Connector........................................................................................................ Twisted Pair RJ45
Cable compatible ......................................................................................UTP 100-ohm Cat5
Input/Output Impedance..................................................................................... 10 kΩ/30 Ω
Audio
Number of Channels ......................................................................................................... 1-to-4
Type ............................................................................................................... Balanced, line level
Impedance .........................................................................................................................>15K Ω
Maximum Input Level ..................................................................................................... 24 dBu
Quantization.............................................................................. 24 bits, 128x (oversampled)
Sample Rate.....................................................................................................................48kS/sec
Frequency Response .................................................................... ±0.1 dB, 20 Hz to 20 KHz
