GUIDE TO INSTALLATION AND OPERATION
Kaleido-Solo | 39
Chart Time Scale
Set the horizontal time scale of the histogram to the desired duration:
20 Sec
2 Min
5 Min
10 Min
15 Min
30 Min
Short Term
Checked Display the short term trace in both loudness charts.
Unchecked Hide the short term trace in both loudness charts.
Integrated
Checked Display the integrated trace in both loudness charts.
Unchecked Hide the integrated trace in both loudness charts.
Target (Dialnorm)
Checked Display the target trace in both loudness charts.
Unchecked Hide the target trace in both loudness charts.
Display
+9 Both loudness charts will use a scale of -41.0 LUFS/LKFS to -14.0 LUFS/LKFS (-18.0 LU/dB to +9.0
LU/dB).
+18 Both loudness charts will use a scale of -59.0 LUFS/LKFS to -5.0 LUFS/LKFS) (-36.0 LU/dB to +18.0
LU/dB).
Compact Display the compact form of both loudness charts. The compact form includes the momentary meter
and measurement summary. In this case the momentary meter will use the +9 scale.
