141
MAINTENANCE
Headlamp Adjustment
The headlamp should shine straight ahead of the
motorcycle. The top of the headlamp High beam
should be just below the center of the lamp at a
distance of 25 feet (7.62 m).
1. Check and adjust the tire pressure.
2. Verify suspension sag is 19-32mm (see page 107)
before adjusting headlight.
3. Straddle the motorcycle in an upright position
and sit in the operator’s seat.
4. Set the ignition switch to the ON position and
set the headlamp to High beam. Check the
headlamp for correct aim.
5. To adjust the headlamp, remove the headlamp
bezel to expose the adjusting screws. Turn the
desired adjusting screw clockwise one
revolution, and turn the screw directly across the
headlamp counterclockwise one revolution.
Repeat if necessary, one revolution at a time.
6. Reinstall the headlamp bezel.
25 feet (7.62 m)
Center of Headlamp
1. Headlamp Adjusting Screws (Bezel Removed)
1
1
