Using Fixed Cycles
2.3 PATTERN DEF pattern definition
2
60
TNC 640 | User's Manual Cycle Programming | 3/2014
2.3 PATTERN DEF pattern definition
Application
You use the
PATTERN DEF function to easily define regular
machining patterns, which you can call with the
CYCL CALL PAT
function. As with the cycle definitions, support graphics that
illustrate the respective input parameter are also available for
pattern definitions.
PATTERN DEF is to be used only in connection with
the tool axis Z.
The following machining patterns are available:
Machining patterns Soft key Page
POINT
Definition of up to any 9 machining
positions 62
ROW
Definition of a single row, straight or
rotated 62
PATTERN
Definition of a single pattern,
straight, rotated or distorted 63
FRAME
Definition of a single frame, straight,
rotated or distorted 64
CIRCLE
Definition of a full circle 65
PITCH CIRCLE
Definition of a pitch circle 66
