Kitchen Mixer Tap
Introduction
We congratulate you on the purchase of
your new appliance. You have chosen a
high quality appliance. The instructions
for use are to be considered as part of the product.
Before you start the installation please read through
all of these instructions and take note of the advice
they contain. These instructions contain important
information about installation, settings and product
care. Keep these instructions safe and if you pass
on the product to anyone else please pass on the
documentation as well.
Intended use
The product is designed only for the regulation of
the hot and cold water flow. It is only intended to
be installed in sink units. This product is suitable for
use with all pressure-resistant hot water systems such
as central heating, continuous-flow water heater,
pressure boiler etc. It is not suitable for low pressure
water heaters such as wood-burning or coal-burning
domestic hot water geysers, oil or gas-fired hot
water geysers, or open electrically heated cylinders.
If in doubt, please consult a plumber or heating
specialist. Any use other than that described here,
or any modification to the product, is not permitted
and may lead to damage to persons or property.
There is also the risk of injury and loss of life. The
product is for private use only and is not intended
for medical or commercial use. The manufacturer
does not accept any liability for any damage
caused by improper use.
Description of parts and
features
1
1 Handle*
2
1 Locking screw *
3
1 hot / cold plaque*
4
1 Spray head
5
1 tap body*
6
1 Rubber seal (shower hose)
7
1 Sealing ring (tap body)
8
2 Thread bolts
9
1 C Sealing washer
10
1 C Metal plain washer
11
2 Securing nuts
12
1 Shower hose
13
2 Screws
14
1 Hose weight
15
1 Rubber seal (short connection hose)
16
2 long connection hoses
17
2 Union nuts with seal*
18
1 Union nut*
19
1 Short connection hose
20
1 cartridge covering ring*
21
1 Cartridge retaining ring*
22
1 Adjusting ring*
23
1 Cartridge*
24
1 Aerator*
25
1 Aerator button
26
1 Shower button
27
1 Allen wrench (2.5 mm)
* prefitted
Technical data
Connections:
G ⅜“
Shower hose:
G ½“, length 120 cm
Safety advice
RISK OF FATAL
INJURY AND ACCIDENTS FOR
INFANTS AND SMALL CHIL-
DREN! Never leave children unsupervised with
the packaging materials. Danger of suffocation.
Keep out of the reach of children. It is not a toy.
BEWARE OF ELECTRIC SHOCK!
Any leaks or the escape of water can
lead to danger to life from electric
shock. Carefully check that all connections are
watertight. Also ensure that all wires of electric
