31 GB/MT
appliances are correct and have been securely
installed.
CAUTION! RISK OF INJURY! Please ensure
that no parts are damaged and that all parts
are correctly assembled. Incorrect assembly
could lead to injury. Please note that washers
and gaskets are wear parts and therefore will
need to be replaced from time to time. Dam-
aged parts could adversely affect safety and
proper function.
When the scald protection is defective or not
activated, hot water can lead to scalding. There-
fore activate the scald protection as is described
in Chapter „Scald protection“ and check the
settings very carefully.
CAUTION! Ensure that the hot / cold water
plaque
3 has been attached the right way
round. The correct position is: left = red (hot
water), right = blue (cold water).
ATTENTION! DANGER OF MATERIAL
DAMAGE! Installation may only be carried
out by experts. Leakage or escape of water can
cause significant damage to buildings and house-
hold contents. All connections must therefore be
checked carefully to ensure that they are tight.
Ensure that all seals are correctly seated to
avoid escape of water due to leakage.
Familiarise yourself with all local conditions, e.g.
water connections and shut-off device, prior to
installation.
We recommend the installation of a filter or an
angle valve. In this way you will protect the
entrance of the taps from foreign bodies and
protect the cartridge
23 from damage.
The product is intended to be only used in
rooms with a temperature above 0° C. In case
of potential frost, cut off the water supply and
drain the taps.
Assembly
Note: Familiarise yourself with the product prior to
assembly. Carefully read the following assembly
instructions and safety advice. In the event of incor-
rect installation, all warranty claims – particularly
in relation to subsequent damage – are excluded.
CAUTION! Before you start installation turn
off the water supply at the mains. Otherwise
there is a danger of injury and / or damage to
the product.
CAUTION! Do not twist the connection hoses
19 or place them under tension.
Note: To do this you will require a Phillips
screwdriver, a slotted screwdriver and an
open-end wrench SW 10 mm.
Follow these steps:
CAUTION! Ensure that you only tighten the
connection hoses
16 , 19 manually. Do not use
pliers or a wrench. Otherwise the product
could be damaged.
Screw the two long connection hoses 16 by
hand into the two external bores in the tap.
Screw the short connection hose 19 by hand
into the middle bore of the tap.
Insert the free end of the shower hose 12 from
the top through the tap body 5 .
Using a slotted screwdriver, screw the two thread
bolts 8 as far as they will go into the tap
body 5 and remove the two securing nuts 11 .
Lay the sealing ring 7 in the nut on the bottom
of the tap body 5 and plug this into the open-
ing on your sink.
Under the sink, attach first the C sealing washer
9 and then C metal washer 10 to the thread
bolts 8 .
The screw the two locking nuts 11 onto the
thread bolts 8 and tighten then with the open-
end spanner SW 10 mm until the tap is seated
firmly on the sink.
Lay the rubber seal 6 into the union nut of the
shower hose 12 and screw the union nut onto
the thread of the rinsing spray 4 .
Lay the rubber seal 15 into the union nut 18 of
the short connection hose 19 and connect this
to the shower hose 12 .
Fasten the hose weight 14 to the shower hose
12 at the bottom of the sink in such as way that
the rinsing spray 4 can be pulled out of the
tap sufficiently and can still be held securely in
the inserted position.
Fasten the two long connection hoses 16 to the
pre-mounted seals 17 or to the angle valves, if
Safety advice / Assembly
