34 GB
Maintenance and Cleaning / Disposal / Information / Warranty and Service
contamination of the water. This becomes evident
when the handle
23 becomes difficult to move. A
new cartridges 28 can be obtained from the listed
service office.
Note: this step requires an open-end spanner
SW 32 mm or fitting pliers.
Proceed as follows to replace the cartridge 28 :
Shut off the main water supply. Allow any
remaining water in the pipework to drain.
Remove the hot / cold plaque 25 by adjusting
the handle 23 to the highest position and in-
serting a flat object between the edge of the
hot / cold plaque
25 and the outside of the
handle 23 .
Note: use light pressure to carefully push the
hot / cold plaque
25 outward so as not to
scratch the surface.
Loosen the locking screw 24 with the socket
head wrench 21 by turning it counter-clockwise.
CAUTION! Do not completely unscrew the
locking screw
24 . Only loosen this as far as is
necessary to remove the handle 23 .
Remove the handle 23 .
Unscrew the cartridge covering ring 26 , do not
use pliers or a spanner. Otherwise the product
could be damaged.
Loosen the cartridge locknut 27 inside using
fitting pliers or an open-end spanner SW 32 mm,
and pull the entire cartridge
28 out of the
fitting 1 .
Insert the new cartridge (model 25M LED) into
the fitting 1 in the same manner.
Note: be sure the seal under the cartridge 28
is correctly seated. Make sure that the guides
are in the corresponding holes.
Reassemble all the above parts. Tighten the
cartridge lock nut 27 using fitting pliers or an
open-end spanner SW 32 mm while simultane-
ously securing the fitting from twisting. This will
achieve tightness and ensure the handle is not
difficult to move.
CAUTION! Be careful not to revere the hot/
cold water plaque
25 . The correct placement is:
left = red (hot water),
right = blue (cold).
Disposal
The packaging is made of environmen-
tally friendly materials, which may be
disposed of through your local recycling
facilities.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.
Information
Potability of tap water
Please consult your local authorities on the
potability of water in your town / municipality.
The following general recommendations apply to
the potability of tap water:
Let the water run freely for a short time if it has
been stagnating in the pipework for more than
four hours. Do not use any of this stagnant
water in the preparation of food or for drinking.
This applies particularly as far as babies and
infants are concerned. Otherwise health con-
cerns can arise. Fresh water can be readily dis-
tinguished from stagnant water as fresh water
is noticeably cooler as it leaves the pipe.
Do not use stagnant water from chromium-plated
pipework to prepare food, for drinking, or for
personal hygiene if you are allergic to nickel.
This water may contain high quantities of nickel
and trigger an allergic reaction.
Do not use water from lead pipework for
preparing food baby food and / or to prepare
foods during pregnancy. Lead dissolves in
drinking water and is particularly damaging to
the health of babies and young children.
Warranty and Service
The warranty period is three years and begins on
the day of purchase. Please keep your receipt as
proof of purchase.
