UPS
CONFIGURATION
The table below illustrates all the possible configurations available to the user in order to best adapt the UPS to individual
requirements. It is possible to perform these operations using the Upstools software.
FUNCTION DESCRIPTION DEFAULT POSSIBLE CONFIGURATIONS
Output frequency
Selects the nominal output
frequency
Auto
 50 Hz
 60 Hz
 Auto: automatic learning of the input frequency
Output voltage
Selects the nominal output
voltage
230V 220 - 240 in 1V steps
Operating mode
Selects one of the 4
different operating modes
ON LINE
 ON LINE
 ECO
 SMART ACTIVE
 STAND-BY OFF (MODE 1)
Bypass operation
Selects the mode of use of
the bypass line
Normal
 Normal
 Disabled with input/output synchronisation
 Disabled without input/output synchronisation
Power-off due to
minimum charge
Automatic UPS power-off in
battery operation mode if
the charge is lower than 5%
Disabled
 Enabled
 Disabled
Autonomy limit
Maximum battery operation
time
Disabled
 Disabled (complete battery discharge)
 (1 - 65000) sec. in 1 sec steps
Battery low
warning
Estimated autonomy time
remaining for the battery
low warning
3 min. (1 - 255) min. in 1 min steps
Battery test
Interval of time for the
automatic battery test
40 hours
 Disabled
 (1 - 1000) h in 1 hour steps
Maximum charge
alarm threshold
Selects the user overcharge
limit
Disabled
 Disabled
 (0 - 103) % in 1% steps
Input frequency
tolerance range
Selects the permitted range
for the input frequency for
switching to the bypass and
for the synchronisation of
the output
± 5% (±3 - ±10) % in 1% steps
* For configurations of the Fout = 50, 60Hz or if the sync is disabled with the input, the UPS downgrades the output
power.
