RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
V
General-Purpose Oscilloscopes
This book covers the following four types of DS1000E, DS1000D Series Digital
Oscilloscopes:
DS1102E, DS1052E
DS1102D, DS1052D (With Logic Analyzer)
DS1000E, DS1000D series are kinds of economical digital oscilloscope with
high-performance. DS1000E series are designed with dual channels and 1 external
trigger channel. DS1000D series are designed with dual channels and 1 external
trigger channel as well as 16 channels logic analyzer.
The front panel of DS1000E, DS1000D series digital oscilloscopes are clear, direct
viewing and easy to use, which consistent with the traditional instrument use fully.
To speed up the adjustment and measurement, please press AUTO button to get
suitable waveform display and settings. Besides, 1GSa/s maximum real-time sample
rate, 25GSa/s maximum equivalent sample rate and the powerful trigger and
analyzer functions enable users view or capture the waveform more detailed and
faster.
Main Features
 Dual analog channels, 1GSa/s maximum real-time sample rate and 25GSa/s
maximum equivalent sample rate, Bandwidth of per channel:
100MHz (DS1102E, DS1102D)
50MHz (DS1052E, DS1052D)
 Optional 16 digital channels (DS1000D series), each channel can be turned on
or off independently, or in a 8 bit group
 5.6 inch and 64 k TFT LCD
 Abundant trigger types: Edge, Pulse Width, Video, Slope, Alternate, Pattern and
Duration Trigger (Only for DS1000D series)
 Unique adjustable trigger sensitivity enables to meet different demands
 Enable to measure 22 types of wave parameters and track measurements via
cursor automatically
 Unique waveform record and replay function
 Fine delayed scan function
 Built-in FFT function, hold practical digital filters
