9
EN
Switching the Input Connector
As the monitor has two sets of input connectors, you can
switch between two input video signals. It is necessary to
select the connector type (HD15/5 BNC's) correctly
according to the connection.
1
Press the COLOR button.
The “COLOR TEMPERATURE/INPUT” selection OSD
(On Screen Display) appears.
2
Press the > ./> buttons to select “INPUT” and then
press the ¨ ?// button to select “HD15” or “BNC.”
When you switch between input sources, the monitor screen
is muted for a moment (Mute) then the signal through the
selected input is displayed. If the selected input do not
receive any video signals, the monitor automatically returns
to the other input after Mute and the “COLOR
TEMPERATURE/INPUT” selection OSD appears.
To erase the “COLOR TEMPERATURE/INPUT” selection
OSD, press the COLOR button again.
The OSD automatically disappears 30 seconds after you
release the buttons.
If two computers are connected to the monitor (one to each
input), when one of the computers is turned on or restarted,
or the monitor goes into power saving mode, the monitor
may switch to the other input because the signal is
temporarily interrupted. Select the input which you use,
following the above steps.
Resetting the Adjustment
Data to Factory-preset Levels
To reset an adjustment item
Press the button of the adjustment item you want to reset,
and then press the RESET button before the OSD (On
Screen Display) disappears.
To reset the brightness, contrast, size,
center, and pincushion at once (for the
received signal)
Press the RESET button with something like a pen for 1
second when no OSD is shown.
COLOR TEMPERATURE
INPUT:
SET SELECT
HD1 5 BNC COLOR
/
RESET
RESET
To reset all adjustment data to factory-
preset levels
Press and hold the RESET button for more than 2 seconds.
All adjustment data including the brightness and contrast
are reset to factory-preset levels.
