Sony BRIGHTERA VPL-FH30 - Manual (Page 4)

4
Other Features
Picture-by-Picture
With this feature, users
can project two different
images at the same
time, greatly expanding
creative possibilities and
enabling exciting new
applications.
Screen Aspect
When screen and image aspect ratios do not match*, this
function fits the projected image to the screen. So, even when
images are switched between different aspect signals, the
projected image can always fit the screen.
* Using the same aspect ratio between screen and projector is ideal.
Quiet Noise Operation
Low noise fans designed to produce lower frequency sounds
to be less obtrusive
Closed Captioning
Official teletext broadcasting, developed by the NCI, USA
Security Pack
Security lock (password and mechanical), security bar, panel
key lock, and security label
Test Pattern Key
For easy screen adjustment
ID Mode
For individual control of multiple projectors
Freeze Function
Freezes the projected image
Smart APA
Auto pixel alignment
Direct Power On/Off
Direct power control using the circuit breaker on the switch
board
High Altitude Mode
For projector operation at high altitude
Network and Control
Controls and monitors projector status
Compatible with various control systems
DICOM GSDF Simulation*
The VPL-FH30 is equipped with a new gamma mode, called
DICOM GSDF Simulation. This is ideal for viewing digital
medical imagery for non-diagnostic applications.
* Follows GSDF (Grayscale
Standard Display
Function) medical
standards for DICOM
(Digital Imaging and
Communications in
Medicine).
* This function is for training
and reference only, and
cannot be used for
medical diagnosis.
Lamp and Filter Synchronized Maintenance
When the air filter must be cleaned, a timely message is
displayed on screen. The lamp and the filter are accessible
from the same side, so their maintenance can be performed
without uninstalling the projector. With typical usage, the
filters have an approximate
15000-hour cleaning
cycle. This is achieved by
a Quad Filter system which
means the filters only need
to be cleaned when the
lamp is changed, even in
harsh conditions, saving
maintenance time and
cost.
simulated images
Fine mesh filters
Normal mesh filters
Hybrid element
Air flow direction
Quad Filter System
Gamma curve*
Standard 2.2 DICOM GSDF simulation simulated images
0 200 400 600 800 1000
0
10
20
30
40
50
60
70
80
90
100
Output luminance [%]
Input level
Standard 2.2
DICOM GSDF sim.
*Based on internal testing.
