Assembling Front Half of Rack (Long Bed)
5. With someone’s assistance, carefully lift the
front half of the rack and attach each leg to the
gussets on the front crossbar as shown. Hand
tighten hardware.
4. Attach the cab hoop to the front siderails as
shown. Make sure that the drain hole, in the
center of the cab hoop, is facing down. Tighten
cab hoop hardware completely.
The front half of the ladder rack is now
assembled (Long Bed)
CAUTION
the front half of the ladder rack will not stand by itself.
A
I
Fig. 17
Fig. 18
