ZXMP3A16G
Document Number DS33575 Rev. 5 - 2
7 of 8
November 2011
© Diodes Incorporated
A Product Line of
Diodes Incorporated
ZXMP3A16G
ADVAN
CE I
N
F
O
RM
ATI
O
N
Package Outline Dimensions
DIM
Millimeters Inches
DIM
Millimeters Inches
Min Max Min Max
Min Max Min Max
A
- 1.80 - 0.071
D 6.30
6.70
0.248
0.264
A1
0.02
0.10
0.0008
0.004
e
2.30 BSC
0.0905 BSC
A2
1.55
1.65
0.0610
0.0649
e1
4.60 BSC
0.181 BSC
b
0.66 0.84 0.026
0.033 E 6.70 7.30 0.264
0.287
b2
2.90 3.10 0.114
0.122 E1 3.30 3.70 0.130
0.146
C
0.23
0.33
0.009
0.013 L 0.90 - 0.355 -
Note: Controlling dimensions are in millimeters. Approximate dimensions are provided in inches.
Suggested Pad Layout
1.5
0.059
mm
inches
3.8
0.15
2.0
0.079
6.3
0.248
2.3
0.091
2.0
0.079
