DCX69/-16/-25

Document number: DS31264 Rev. 6 - 2

2 of 5

www.diodes.com

April 2012

© Diodes Incorporated

DCX69/-16/-25





Maximum Ratings

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Value

Unit

Collector-Base Voltage

V

CBO

-25 V

Collector-Emitter Voltage

V

CEO

-20 V

Emitter-Base Voltage

V

EBO

-5.0 V

Collector Current

I

C

-1.0 A

Peak Pulse Power

I

CM

-2.0 A


Thermal Characteristics

Characteristic Symbol

Value

Unit

Power Dissipation (Note 4) @ T

A

= 25°C

P

D

1 W

Thermal Resistance, Junction to Ambient Air @ T

A

= 25°C (Note 4)

R

θJA

125 °C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +150

°C



Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Min

Typ

Max

Unit

Test

Conditions

OFF CHARACTERISTICS (Note 5)
Collector-Base Breakdown Voltage

V

(BR)CBO

-25

V

I

C

= -100

μA, I

E

= 0

Collector-Emitter Breakdown Voltage

V

(BR)CEO

-20

V

I

C

= -10mA, I

B

= 0

Emitter-Base Breakdown Voltage

V

(BR)EBO

-5.0

V

I

E

= -100

μA, I

C

= 0

Collector-Base Cutoff Current

I

CBO

-100

-10

nA

μA

V

CB

= -25V, I

E

= 0

V

CB

= -25V, I

E

= 0, T

A

= 150°C

Emitter-Base Cutoff Current

I

EBO

-100 nA

V

EB

= -5.0V, I

C

= 0

ON CHARACTERISTICS (Note 5)

DC Current Gain

DCX69, DCX69-16, DCX69-25

h

FE

50
60




V

CE

= -10V, I

C

= -5.0mA

V

CE

= -1.0V, I

C

= -1.0A

DCX69

85

375

⎯ V

CE

= -1.0V, I

C

= -500mA

DCX69-16

100

250

⎯ V

CE

= -1.0V, I

C

= -500mA

DCX69-25

160

375

⎯ V

CE

= -1.0V, I

C

= -500mA

Collector-Emitter Saturation Voltage

V

CE(SAT)

-0.5 V

I

C

= -1.0A, I

B

= -100mA

Base-Emitter Turn-On Voltage

V

BE(ON)


-0.7
-1.0

V

V

CE

= -10V, I

C

= -5mA

V

CE

= -1.0V, I

C

= -500mA

SMALL SIGNAL CHARACTERISTICS

Current Gain-Bandwidth Product

f

T

40 200

MHz

V

CE

= -5.0V, I

C

= -50mA,

f = 100MHz

Output Capacitance

C

obo

17

pF

V

CB

= -10V, f = 1MHz

Notes:

4. Device mounted on FR-4 PCB; pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com.

5. Measured under pulsed conditions. Pulse width = 300

μs. Duty cycle ≤2%.
