AP5002

PWM CONTROL 2A STEP-DOWN CONVERTER

AP5002 Rev. 8

3 of 10

FEBRUARY 2009

www.diodes.com

©

Diodes Incorporated

Absolute Maximum Ratings


Symbol

Parameter

Rating

Unit

ESD HBM

Human Body Model ESD Protection

5

KV

ESD MM

Machine Model ESD Protection

200

V

V

CC

V

CC

Pin Voltage

V

SS

- 0.3 to V

SS

+ 22

V

V

FB

Feedback Pin Voltage

V

SS

- 0.3 to V

CC

V

V

EN

EN Pin Voltage

V

SS

- 0.3 to V

IN

V

V

OUTPUT

Switch

Pin

Voltage V

SS

- 0.3 to V

IN

V

P

D

Power Dissipation

1000

mW

T

J

Operating Junction Temperature Range

-20 to +125

o

C

T

ST

Storage Temperature Range

-65 to +150

o

C

Caution: The absolute maximum ratings are rated values exceeding which the product could suffer physical damage. These values must therefore not be

exceeded under any conditions.


Recommended Operating Conditions


Symbol

Parameter

Min

Max

Unit

V

IN

Input

Voltage

3.6

20

V

I

OUT

Output

Current

0

2

A

T

A

Operating

Ambient

Temperature

-20

85

o

C
