FZT1051A
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
150 V
Collector-Emitter Voltage V
CEO
40 V
Emitter-Base Voltage V
EBO
7 V
Continuous Collector Current I
C
5 A
Peak Pulse Current I
CM
10 A
Base Current I
B
1 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 5)
P
D
3.0
W
(Note 6) 2.0
(Note 7) 1.6
(Note 8) 1.2
Thermal Resistance, Junction to Ambient
(Note 5)
R
JA
41.7
°C/W 
(Note 6) 62.5
(Note 7) 78.1
(Note 8) 104
Thermal Resistance Junction to Lead (Note 9) R
JL
10.9
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
ESD Ratings
(Note 10)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 8,000 V 3B
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 5. For a device mounted with the collector lead on 52mm x 52mm 2oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under
still air conditions whilst operating in a steady-state.
6. Same as note (5), except the device is mounted on 25mm x 25mm 2oz copper.
7. Same as note (5), except the device is mounted on 25mm x 25mm 1oz copper.
8. Same as note (5), except the device is mounted on minimum recommended pad layout.
9. Thermal resistance from junction to solder-point (at the end of the collector lead).
10.Refer to JEDEC specification JESD22-A114 and JESD22-A115.
