FZT751
Document Number DS32208 Rev. 7 - 2
4 of 7
January 2013
© Diodes Incorporated
FZT751
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-80
−
−
V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 11)
BV
CEO
-60
−
−
V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7
−
−
V
I
E
= -100µA
Collector Cut-off Current
I
CBO
−
<1
-100 nA
V
CB
= -60V
−
−
-10 µA
V
CB
= -60V, T
amb
= 100°C
Emitter Cut-off Current
I
EBO
−
<1
-100 nA
V
EB
= -4V
Collector-Emitter Saturation Voltage (Note 11)
V
CE(sat)
−
-0.15 -0.3
V
I
C
= -1A, I
B
= -100mA
−
-0.45 -0.6
I
C
= -3A, I
B
= -300mA
Base-Emitter Saturation Voltage (Note 11)
V
CE(sat)
−
-0.9 -1.25 V I
C
= -1A, I
B
= -100mA
Base-Emitter Turn-On Voltage (Note 11)
V
BE(on)
−
-0.8 -1.0 V I
C
= -1A, V
CE
= -2V
DC Current Gain (Note 11)
h
FE
70 200
−
−
I
C
= -50mA, V
CE
= -2V
100 200 300
I
C
= -500mA, V
CE
= -2V
80 170
−
I
C
= -1A, V
CE
= -2V
40 150
−
I
C
= -2A, V
CE
= -2V
Current Gain-Bandwidth Product (Note 11)
f
T
100 140
−
MHz
V
CE
= -5V, I
C
= -100mA
f = 100MHz
Turn-On Time
t
on
−
40
−
ns
V
CC
= -10V, I
C
= -500mA
I
B1
= I
B2
= -50mA
Turn-Off Time
t
off
−
450
−
ns
Output Capacitance (Note 11)
C
obo
−
−
30 pF
V
CB
= -10V, f = 1MHz
Notes:
11. Measured under pulsed conditions. Pulse width ≤ 300 µs. Duty cycle ≤ 2%
