FMMT560
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
-500 — — V I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 8) BV
CEO
-500 — — V I
C
= -1mA
Emitter-Base Breakdown Voltage BV
EBO
-7 — — V I
E
= -100µA
Collector Cutoff Current I
CBO
— — -100 nA V
CB
= -500V
Emitter Cutoff Current I
EBO
— — -100 nA V
EB
= -5V
Static Forward Current Transfer Ratio (Note 8) h
FE
100
80
—
—
—
15
300
300
—
—
I
C
= -1mA, V
CE
= -10V
I
C
= -50mA, V
CE
= -10V
I
C
= -100mA, V
CE
= -10V
Collector-Emitter Saturation Voltage (Note 8) V
CE(sat)
— —
-200
-500
mV
I
C
= - 20mA, I
B
= -2mA
I
C
= - 50mA, I
B
= -10mA
Base-Emitter Saturation Voltage (Note 8) V
BE(sat)
— — -0.9 V I
C
= -50mA, I
B
= -10mA
Base-Emitter Turn-On Voltage (Note 8) V
BE(on)
— — -0.9 V I
C
= -50mA, V
CE
= -10V
Output Capacitance C
obo
— — 8 pF V
CB
= -20V, f = 1MHz
Transition Frequency f
T
60 — — MHz
V
CE
= -20V, I
C
= -10mA,
f = 50MHz
Turn-On Time t
on
— 110 — ns V
CE
= -100V, I
C
= -50mA,
I
B1
= -5mA, I
B2
= 10mA Turn-Off Time t
off
— 1.5 — µs
Notes: 8. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%
