MMSZ5221BS -MMSZ5259BS
Document number: DS31038 Rev. 12 - 2
2 of 4
www.diodes.com
June 2008
© Diodes Incorporated
MMSZ5221BS - MMSZ5259BS
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Zener Voltage Range (Note 5)
Test
Current
Maximum Zener
Impedance (Note 6)
Maximum Reverse
Leakage Current (Note 5)
V
Z
@ I
ZT
I
ZT
Z
ZT
@
I
ZT
Z
ZK
@ I
ZK
= 0.25mA
I
R
@ V
R
Type
Number
Marking
Code
Nom (V)
Min (V)
Max (V)
mA
Ω
μA
V
MMSZ5221BS
C1
2.4
2.28
2.52
20
30
1200
100
1.0
MMSZ5223BS
C3
2.7
2.57
2.84
20
30
1300
75
1.0
MMSZ5225BS
C5
3.0
2.85
3.15
20
30
1600
50
1.0
MMSZ5226BS
G1
3.3
3.14
3.47
20
28
1600
25
1.0
MMSZ5227BS
G2
3.6
3.42
3.78
20
24
1700
15
1.0
MMSZ5228BS
G3
3.9
3.71
4.10
20
23
1900
10
1.0
MMSZ5229BS
G4
4.3
4.09
4.52
20
22
2000
5.0
1.0
MMSZ5230BS
G5
4.7
4.4 7
4.94
20
19
1900
5.0
2.0
MMSZ5231BS
E1
5.1
4.85
5.36
20
17
1600
5.0
2.0
MMSZ5232BS
E2
5.6
5.32
5.88
20
11
1600
5.0
3.0
MMSZ5233BS
E3
6.0
5.70
6.30
20
7
1600
5.0
3.5
MMSZ5234BS
E4
6.2
5.89
6.51
20
7
1000
5.0
4.0
MMSZ5235BS
E5
6.8
6.46
7.14
20
5
750
3.0
5.0
MMSZ5236BS
F1
7.5
7.13
7.88
20
6
500
3.0
6.0
MMSZ5237BS
F2
8.2
7.79
8.61
20
8
500
3.0
6.5
MMSZ5238BS
F3
8.7
8.27
9.14
20
8
600
3.0
6.5
MMSZ5239BS
F4
9.1
8.65
9.56
20
10
600
3.0
7.0
MMSZ5240BS
F5
10
9.50
10.50
20
17
600
3.0
8.0
MMSZ5241BS
H1
11
10.45
11.55
20
22
600
2.0
8.4
MMSZ5242BS
H2
12
11.40
12.60
20
30
600
1.0
9.1
MMSZ5243BS
H3
13
12.35
13.65
9.5
13
600
0.5
9.9
MMSZ5245BS
H5
15
14.25
15.75
8.5
16
600
0.1
11
MMSZ5246BS
J1
16
15.20
16.80
7.8
17
600
0.1
12
MMSZ5248BS
J3
18
17.10
18.90
7.0
21
600
0.1
14
MMSZ5250BS
J5
20
19.00
21.00
6.2
25
600
0.1
15
MMSZ5251BS
K1
22
20.90
23.10
5.6
29
600
0.1
17
MMSZ5252BS
K2
24
22.80
25.20
5.2
33
600
0.1
18
MMSZ5254BS
K4
27
25.65
28.35
5.0
41
600
0.1
21
MMSZ5255BS
K5
28
26.60
29.40
4.5
44
600
0.1
21
MMSZ5256BS
M1
30
28.50
31.50
4.2
49
600
0.1
23
MMSZ5257BS
M2
33
31.35
34.65
3.8
58
700
0.1
25
MMSZ5258BS
M3
36
34.20
37.80
3.4
70
700
0.1
27
MMSZ5259BS
M4
39
37.05
40.95
3.2
80
800
0.1
30
Notes: 5. Short duration pulse test used to minimize self-heating effect.
6. f = 1KHz.
