Example of antenna grounding
Ground clamp
Power service grounding
electrode system (NEC
Article 250, Part H)
Antenna lead-in wire
Ground clamps
Antenna discharge unit (NEC
Section 810-20)
Electronic service
equipment
Grounding conductors (NEC
Section 810-21)
Figure 1. Proper grounding for the cable
