35
GASKET
INDICATOR
PLATE
ACTUATOR
LINKAGE
ADAPTER
VALVE TOP
HEX HEAD
BOLTS (2)
U-BOLT &
HEX NUTS
VALVE SHAFT
HORIZONTAL
SHAFT
8 mm HEX NUTS (2)
(ON BOTTOM SIDE
OF BRACKET)
HEX NUTS (2)
Figure 4-2. Actuator and Linkage Installation Details
