5 Modular Block System: Emergency Stop Circuits
Emergency stop monitoring
with manual start (start-up and operation), category 4 8-6
Emergency stop monitoring
with automatic start-up, manual start (operation)
and function test, category 4
8-8
Feedback loop monitoring
Shutdown with two contactors connected in series,
category 4
8-10
Feedback loop monitoring
Shutdown with two main contactors connected in series and
pulsed outputs, category 4
8-12
Feedback loop monitoring (selective shutdown),
category 4 8-14
Emergency stop monitoring with monitoring of feedback loop,
category 4 8-18
Appendix
9-1
Assignment table
Category and requirement class 9-1
Standard function blocks: current versions 9-2
Changes to the standard function blocks 9-3
SB060: Emergency stop monitoring 9-3
SB061: Emergency stop monitoring 9-3
SB062: Emergency stop monitoring 9-4
SB063: Emergency stop monitoring 9-5
SB065: Feedback loop monitoring (RFK) 9-5
SB067: Feedback loop monitoring (RFK) 9-5
SB070: Initialisation of administration data block (DB015) 9-5
SB071: Initialisation of administration data blocks
(DB015/DB016/DB017)
9-6
Changes to the operating manual 9-6
Changes from Version 1.3 to Version 2.0 9-6
Changes from Version 2.0 to Version 2.2 9-6
