Main frame – Nexen BD 933617 User Manual
Page 11
11
FORM NO. L-20271-F-0609
In accordance with Nexen’s policy of product improvement, the specifications and technical data contained in this manual are subject to change without notice and
are based on the latest information available at the time of printing.
ITEM
DESCRIPTION
QTY
14
1
Sleeve Bearing
2
15
1
Sleeve Bearing
4
16
Detent Pin
2
17
1
Extension Spring
2
18
1,2
Machine Screw
8
24
Cap Screw
4
27
Set Screw
2
28
Hex. Nut
2
29
1,2
Belleville Disc Spring
4
30
1
Sleeve Bearing
2
ITEM
DESCRIPTION
QTY
1
Main Frame
1
2
Brake Arm
2
3
Shoe
2
4
1,2
Friction Facing
2
5
Spring Clip
2
6
Pivot Pin Retaining Plate
1
7
Pivot Pin (Arm)
2
8
Adjustment Screw
1
9
Adjustment Screw Retaining Ring
1
12
Spanner Nut
1
FIGURE 13
2
2
9
12
8
5
17
1
27
28
30
15
3
4
18
16
14
7
6
24
5
29
MAIN FRAME
1
Denotes Repair Kit items.
Repair Kit Product No. 933598.
Friction Facing Kit Product No. 933599.
2
Denotes Facing Kit items.
Friction Facing Kit Product No. 933599.
