9
•
Press REC button again to stop recording. -> LED is flashing for a
short time, then LED light is stably on again.
Note: Do not remove the USB storage device if the LED is flashing.
Mains connection
Ensure that the mains voltage of your home corresponds to the operating
voltage of the unit. Your unit is ready to be connected to a correct voltage
of your location.
Amplifier connection
Connect RCA line out cable (10) to the AUX input on your amplifier:
-
Red plug into R channel input.
-
White plug into L channel input.
-
Place the record of your choice on the turntable. If it is a 45 rpm, do
not forget to place the adaptor (1) on the record spindle.
-
Choose the desired playing speed:
o
33 rpm -> button unlocked
o
45 rpm-> button locked.
-
Release the pick-up arm clip.
-
Place the cartridge vertically over the first track of the record, the
turntable starts turning.
-
When the record is over, the pick-up arm returns to its rest , the
turntable stops turning
Take care that the pick-up lift stick is in forward-turned (lift down),
close pick-up arm lock to secure pick-up arm.
Technical specification
Power Supply: 230V, 50Hz
Power Consumption: <10W
Wow & Flutter: 0.25%
Distortion: 3%~4%
S/N: 50 dB
Audio Output Voltage: 500mV ±200mV
USB: 5V/500 mA
