Lenco SCD-37 USB - Manual (Page 7)

GB 5
MP3 / WMA / USB display
" PROGRAM "
7. Press “ STOP ” button once to stop programmed
playback.
8. Press “ PLAY/PAUSE ” button to resume
programmed playback.
9. Open the CD door, turn off the CD player or press
“ STOP ” button twice to clear the programmed
memory.
Note : Programming can only be made when the player
is in stop mode.
CLEANING THE UNIT
Do not use volatile chemicals on this unit. Clean by lightly
wiping with a soft cloth.
IMPORTANT NOTE
If an abnormal display indication or an operating problem
occurs, disconnect the AC power cord and remove the
batteries. Wait at least 5 seconds, then reconnect the AC
power cord or reinstall the batteries.
WARNING
Should the CD door be opened before the reading of the CD
is completed, a jamming noise may occur. This is resolved
by closing the CD door.
CLEANING CD
If the CD skips or will not play , the disc may need clean-
ing . Before playing, wipe the disc from the centre out with
a cleaning cloth.
After playing, store
the disc in its case.
MAINTENANCE
CLEANING THE CD LENS
If the CD lens is dusty, clean it with a brush-blower. Blow
several times on the lens and remove the dust with the
brush. Finger prints may
be removed with a cotton
swab moistened with
alcohol.
FOR MP3 / WMA / USB PLAYBACK
Programmed playback enables tracks on a disc to be played
in the desired order. Up to 20 tracks can be programmed.
1. Press the “PROGRAM” button.
2. Press the “FOLDER UP” buttons to select the desired
folder.
3. Press the “NEXT ” and “ PREV ” buttons
to select the desired track number.
4. Press ‘PROGRAM” button again to memorize the
selected track.
5. Repeat steps 2 to 4 until all desired tracks are
programmed.
6. Press the “PLAY/PAUSE ” button to start. “ “,
“PROG.” and “MP3” / "WMA / USB" are shown
on the CD display.
SPECIFICATIONS
CD SECTION
Channels: 2 channels
S / N ratio: 60 dB
Wow & Flutter: undetectable
Sampling frequency: 44.1 kHz 8 x over sampling
Quantization: 1 bit DA converter
Pick up light source: Semi - conductor laser
Pick up wave length 790 nm
RADIO SECTION
Tuning ranges: FM 87.5 - 108 MHz
Antennas: FM Rod antenna
GENERAL
Output power: 1.2 W + 1.2 W (RMS)
Power consumption: 8.5 W
Speaker: 3 " 8 OHM
Power source: AC : 230V ~ 50Hz
DC : 9V ( 6 x 1.5V LR14/ "C"/UM2 )
Dimensions: 259(L) x 223(D) x 125(H)mm
Weight 1.3 KGS
Due to continuing improvement, the features and the design are subject to change without notice.
