6-68
Mini Fuse
Usage
21 IGN1
-
UH
Evaporative Emissions (EVAP)
Canister Purge Valve,
Heated Oxygen Sensors 1 and 2,
Mass Air Flow (MAF) Sensor
22 SPARE
Not Used
23 SPARE
Not Used
24 SPARE
Not Used
25 ELEK IGN
Ignition Control Module (ICM)
26 SPARE
Not Used
27 B/U LAMP
Transaxle Range Switch to
Back
-
up Lamps
28 A/C CLU
A/C CLU Relay to A/C
Compressor Clutch Oil
29 RADIO
Driver Information Display,
Heater A/C Control, Radio,
Rear Side Door Actuator Control
Motor, Remote Control Door
Lock Receiver (RCDLR),
Security Indicator Lamp and
Theft
-
Deterrent Shock Sensor
Mini Fuse
Usage
30 ALT SENSE
Generator
31 TCC
Automatic Transaxle (Torque
Converter Clutch Solenoids)
Stoplamp Switch to PCM
32 FUEL PUMP
Fuel Pump Relay
33 ECM SENSE
Powertrain Control Module (PCM)
34
Not Used
35 FOG LP
Fog Lamp Relay
36 HORN
Horn Relay
37 PARK LP
Daytime Running Lamps (DRL)
Control Module, Headlamps and
Instrument Panel Dimmer Switch
Theft
-
Deterrent Relay to Headlamps
38
Not Used
39 AIR
Not Used
Diodes
A/C
CLU DIODE
Air Conditioning Clutch Diode
40
Mini Fuse Puller
