1. When using D C p o wer supply, please beaware of theoperating voltage. Firstof
all, pleasemakesureminimumof 12 volts can beobtained for function properly.
However, the power supply should not exceeditsmaximumcapacity of 15 volts.
When the supply voltageis more than 15 volts, the systemwill suffer severe
internal damage. It is p r eferred t h e p o w e r source is from a regulated power with
the minimum current of 3 A.
2. Use only MIPROstandardantenna to ensure the sensitivity of the receiver.
3. Use only stereoinstead of mono headphone as the monitoring headphone.
4. Antenna sockethas 8-volts DCpower supply; please do notshort thecircuit of
this part.
9
6 . CAUTIONS
ACT MULTI CHANNEL WIRELESS RECEIVER
8
③ This interface system adaptsparallel connection. Therefore, it takes only 2 linking wires to
complete t h e connection to the converter of the whole system.
④
⑤
⑥
This systemcanconnect up to 64receiver modules for simultaneous operation. Hence, if 4
receiver modules are installed ineachACT-707,this controlling system can operate up to
16 ACT-707 receivers.
Thoughlonger thedistance is, worse the stability will be; nevertheless,thenetwork
connecting cable can still operate while it is 3 . However, it is our
recommendation to keep the cableunder 100 meters long t o e n s u r e high-speed
transmission.
Please refer to the LCD module's users manual for softwareoperation.
00 meters long
(Fig.10)
ACT MULTI CHANNEL WIRELESS RECEIVER
CONVERTER
TO PC RS-232 COMPORT
Wire(-)
RX1
Wire(+)
RX2
RX3
