ACTIVE SUBWOOFERS: MS12SA
7. PANEL DESCRIPTION-MS12SA
SPO
TLIGHT
(6)
(7)
(8)
(11) (10) (9) (12)
(4)
(5)
(3)
(11) PHASE Switch Reverse the Polarity of the subwoofer output
(9)
(10)
(12) OUT LEFT/RIGHT ON 2
x
XLR CONNECTOR
BYPASS Switch Select the Hiqh pass filter or by pass (4)
(5)
LINE IN RIGHT.ON XLR CONNECTOR
Ground Lift Switch
SIGNAL/LIMIT, Red LED, indicate ON status
VOLUME main power amplifier control
POWER, Green LED, indicate ON status
Input AC power socket with main fuse
ON-OFF main power switch
(6)
LINE IN LEFT/MONO ON COMBO CONNECTOR (7)
LINK LEFT/RIGHT ON XLR CONNECTOR (8)
(3)
(13) POWER SWITCHUNG BUTTOM
(13)
- 8
VOLUME
MAX
0dB
BY PASS
HPF 80Hz
OUT
SIGNAL
LIMIT
RIGHT LEFT / MONO
IN
POWER
PHASE GND
NORMAL
REVERSE
RIGHT LEFT / MONO
LINK
RIGHT LEFT
MS12SA
DESIGNED IN ITALY
SERIAL MODEL
AC INPUT
POWER
110 -120V 220 -240V
ON OFF
AC INPUT
110-120V 50/60Hz ~
220-240V 50/60Hz ~
110-120V: T6.3AL
220-240V: T3.15AL
AC FUSE
POWER CONSUMPTION: 350W
Use only with a 250V fuse
