23
Rev. A
920-0085
TSM17C Hardware Manual
5.2 Mechanical Outlines
Unit:mm
Model Length”L”
TSM17C-1CG 69.4
TSM17C-2CG 74.9
TSM17C-3CG 83.4
L±1 2±0.2
20±1
15±0.2
Ø6
5.5FLA
T ±0.1
31±0.1
31±0.1
Ø22
0
-0.052
4-M3 Depth 4.5Min 42.3±0.5
43±1
61±0.5
42.3±0.5
72±1
0 -0.012
