2.3 <Connector Reference>
2.3.1 <Internal Connectors>
Connector Function Remark
CPU Socket478 for Intel Pentium M/Celeron M CPU Standard
DIMM 184-pin DDR SDRAM DIMM socket Standard
IDE1 40-pin IDE connector Standard
IDE2 44-pin IDE connector Slim
FDD 26-pin slim type floppy connector Slim
ATX 24-pin ATX power input connector Standard
CN_AUDIO 5 x 2-pin audio connector Standard
CDIN 4-pin CD-ROM audio input connector Standard
CN_DIO 6 x 2-pin digital I/O connector Standard
CN_USB 5 x 2-pin USB connector Standard
CPUFAN 3-pin CPU cooler fan connector Standard
SYSFAN 3-pin system cooler fan connector Standard
CN_LVDS 20 x 2-pin LVDS connector(LV-675X Only) Standard
CN_INV 5-pin LCD inverter connector(LV-675X Only) Standard
CN_IR 5-pin IrDA connector Standard
CN_COM1/2 5 x 2-pin COM1 & COM2 connector Standard
JFRNT 14-pin front panel switch/indicator connector Standard
Mini-PCI 2 x Mini-PCI socket Standard
CN_DVI 26-Pin connector(LV-675D Only) Standard
2.3.2 <External Connectors>
Connector Function Remark
USB_RJ45 Dual USB and one RJ45 LAN connector Standard
VGA DB15 analog VGA connector Standard
KB PS/2 keyboard connector Standard
MS PS/2 mouse connector Standard
AUDIO Audio connectors Standard
SPDIF SPDIF digital audio output connector Standard
S-Video S-video connector on rear I/O panel Standard
TV-Out RCA Jack on rear I/O panel Standard
1394 One IEEE1394 connector on rear I/O panel Standard
LPT One parallel port on rear I/O panel Standard
