12.10.4 <S-Video Interface>
The board provides one S-Video interface up to 1024 x 768 resolution by NTSC/PAL
supported, for three output types with Composite, S-Video and Component .
Notice1: This connector is for both S-Video/Composite outputs; please use attached two
cables in the package for SDTV devices.
Notice2: S-Video and Composite can not be used at the same time.
S-Video TV-Out
