LV-675 User’s Manual
24
2.10.2 <LVDS Display LV-675X Only >
The board provides one 40-pin LVDS connector for 18/24-bit dual channel panels,
supports up to 1600 x 1200 (UXGA) of resolution, with one LCD backlight inverter
connector and one jumper for panel voltage setting.
CN_LVDS
1
2
39
40
1
5
CN_INV
1
3
JVLCD
