LP-171 User’s Manual
-
18
-
19
20
1
1
2
2.8.2 <Digital Display>
The board provides one 20-pin LVDS connector for 18 or 24 bit single channel panels,
supports up to 1920 x 1080 (WUXGA) of resolution, with one LCD backlight inverter
connector and one jumper for panel voltage setting
CN_INV
CN_LVDS
1 5
JVLCD
