Forward Optical Receiver
Operation Manual
2
、
Main Selection Screen
At the main screen press the ENT key to enter into the [MAIN MENU], then use the UP/DOWN keys to select the
following options:
Option Description
STATUS
Present status of the Receiver
SETTINGS Settings
screen
ALARMS Alarms
screen
Return to Main Menu
Return to main screen
3. STATUS selection screen
Selection Description
Optical A
Receiver A input optical power
Optical B
Receiver B input optical power
RF level
Displays RF output level that relative to reference level.
Gain control level
Displays Voltage control attenuator voltage, the upper bond would be 9.5V. The
Voltage higher means attenuation loss is lower.
Power Supply
Displays 12VDC supply, +5VDC current supply and -5VDC current supply
Operating
Information
Displays software version and other reference information
4. SETTINGS selection screen
Selection Function
Description
