16.4 CA 1515-6
Loudspeaker
Design 2-way passive system, bass reflex tuning
Frequency range -10 dB 47 Hz - 22 kHz
Frequency range ±3 dB 77 Hz - 19 kHz
Coverage angles nominal 65° x 50° (hor. x vert.)
Directivity index (DI) 12 (+1.5/-2) 1.2 kHz - 16 kHz
Power handling 500 W nominal1)
Max. SPL 132 dB (SPL peak / 1 m)
Components 15‘‘ low-mid chassis
1.5‘‘ high freq. driver with 75 mm titanium dome
on rotatable CD-horn
Crossover 1.1 kHz 12 dB / octave, self-resetting
protection circuits for speakers and
crossover, all-pass filter for delay time and
phase optimisation
Impedance (nominal) 8 • • •
Connectors 2 x Speakon NL4MP (1+ / 1-)
Enclosure
Multi-purpose enclosure with monitor and
cluster angles, 15 mm Finnish birch Multiplex
with highly resistant black structured paint (PU),
2 butterfly handles,
mounting flange K&M 19656,
ball proof front grille with exchangeable
black acoustic foam
Dimensions (W x H x D) 433 x 680 x 410 mm
Weight 36.4 kg
Options '100 Volt with 300 VA toroidal transformer’
‘Barrier strip instead of Speakon connectors'
'Outdoor Mobile' and 'Outdoor Installation'
‘Special finish in RAL colours’
Accessories see catalogue or visit www.kling-freitag.de
