Chapter 7: Technical Specifications
80
A
105.0
DETAIL A
160.0
160
171.5
278.5
425
800.0
189
60.0
Figure 7-5. External Tooling on Top of Robot Arm
Adept Cobra s800 Inverted Robot User's Guide, Rev H1
Page 109 of 142
