Group Name CmdResp Description
Read
/
Write
Min
Value Max
value Default
value
Values Index #1 Index #2
OPATTERN OP OP Output test pattern Rd/Wr0 8 0
0 = No pattern
1 = Vertical Grey Scale
2 = Horizontal Grey Scale
3 = Vertical Color Bar
4 = Horizontal Color Bar
5 = Grid
6 = SMPTE
7 = Burst
8 = Centering
0 = Main output
1 = Preview
output
OBLACK OB OB Output black control Rd/Wr0 1 0
0 = Normal output
1 = Black output
0 = Main output
1 = Preview
output
OUTIL_H OH OH Output H size Rd 0 65535 1600 Unit = pixels
0 = Main output
1 = Preview
output
OUTIL_V OV OV Output V size Rd 0 65535 1200 Unit = pixels
0 = Main output
1 = Preview
output
OFIELDRATE OT OT Output frame frequency Rd 100 10000 6000 Unit = 1/100Hz
0 = Main output
1 = Preview
output
OIMAGE_OVERSCAN OO OO Image Overscan / Underscan Rd/Wr0 1 0
0 = Main output
1 = Preview
output
OSETDETECTHDCP Oh Oh
Enable/disable the Output HDCP
detection
Rd/Wr0 4 1
0 = Disable HDCP detection
1 = Automatic HDCP detection
2 = HDCP Configuration 1
3 = HDCP Configuration 2
4 = HDCP Configuration 3
0 = Main output
1 = Preview
output
OISHDCP On On Output HDCP status Rd 0 1 0
0 = Main output
1 = Preview
output
OSYNCOUTPUT Om Om
Output 2 copies the format and
rate of output 1
Rd/Wr0 1 0
