Chapter 7 : LCD FUNCTIONS DESCRIPTION
1 [INPUT MENU] + ENTER.
1-1 [video standard] + ENTER.
c Select an input with  + ENTER.
d Then select the video standard with  + ENTER.
• [AUTO] = Automatic detection.
• [NTSC (3.58/60 Hz)] = NTSC detection only.
• [PAL (4.43/50 Hz)] = PAL detection only.
• [SECAM (50 Hz)] = SECAM detection only.
• [Black and white 50 Hz] = Black and White at 60 Hz detection only.
• [Black and white 60 Hz] = Black and White at 50 Hz detection only.
1-2 [RGB input] + ENTER.
Select the video type for the RGBS input between:
• [TTL] = RGB/S video signal with TTL Sync.
• [75 ohms] = RGB/S with an analog Sync. (0.3 Vp/p).
2 [OUTPUT MENU] + ENTER.
2-1 [output format] + ENTER.
Select an output format with  + ENTER.
• Doubler (480p at 59.94 Hz or 576p at 50 Hz - 4/3)
• 852 x 480p (Plasma 42” at 50 Hz or 59.94 Hz - 16/9)
• 800 x 600p (at 50 Hz or 59.94 Hz - 4/3)
• 1280 x 720p (HDTV at 50 Hz or 59.94 Hz - 16/9)
• 1024 x 768p (at 50 Hz or 59.94 Hz - 4/3)
• Quadrupler (960p at 59.94 Hz or 1152p at 50 Hz - 4/3)
• 1365 x 768p (at 50 Hz or 59.94 Hz - 16/9)
• 1365 x 1024p (at 50 Hz or 59.94 Hz - 4/3)
NOTE: The output frame rate is 50 Hz for PAL & SECAM video inputs, and 59.94 Hz for NTSC video inputs.
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format corresponding
to the native resolution of the display device. This way, the display device will not have to scale the image
and the result will be better.
2-2 [output sync] + ENTER.
Select the Output Sync. type with  + ENTER.
• [H&V] = Separate H & V Sync.
• [COMP] = Composite Sync.
2-3 [type of screen]
Select an item with  + ENTER.
• [4/3] = if your image is displayed on a 4/3 screen.
• [16/9] = if your image is displayed on a 16/9 screen.
3 [IMAGE MENU] + ENTER.
NOTE: This menu is available and active on the selected video source. This menu is not available for the COMPUTER
INPUT. The image settings and adjustments can be different and separately memorized for each video input.
3-1 [H position] + ENTER.
Adjust the Horizontal position with  + ENTER.
3-2 [V position] + ENTER.
Adjust the Vertical position with  + ENTER.
3-3 [H size] + ENTER.
Adjust the Horizontal size with  + ENTER.
3-4 [V size] + ENTER.
Adjust the Vertical size with  + ENTER.
