ARCHMI-7XX (SBC-7106A) User Manual 53
Signal Name Pin# Pin# Signal Name
5V_USB23 1 2 5V_USB23
NC (USB3_N) 3 4 NC (USB2_N)
NC (USB3_P) 5 6 NC (USB2_P)
Ground 7 8 Ground
NC 9 10 Ground
Note:
Before connection, make sure that pinout of the USB Cable is in accordance with that
of the said tables. Any inconformity may cause system down and even hardware
damages.
JP_SET (option):
(2.0mm Pitch 2x5 Pin Header).
Signal Name Pin# Pin# Signal Name
3P3V_S5_USB 1 2 3P3V_S5
3P3V_S5_USB 3 4 3P3V_S5
3P3V_S5_USB 5 6 3P3V_S5
PSON_ATX 7 8 Ground
PSON_ATX 9 10 Ground
JP6：
(2.0mm Pitch 2x3 Pin Header), COM6 setting jumper, pin 1~6 are used to select
signal out of pin 9 of COM6 port.
JP6 Pin# Function
Close 1-2 RI (Ring Indicator) (default)
Close 3-4 COM6 Pin9=+5V (option)
Close 5-6 COM6 Pin9=+12V (option)
COM6：
(2.0mm Pitch 2X5 Pin Header), COM6 Port, up to one standard RS232 port are
provided. They can be used directly via COM cable connection.
Signal Name Pin# Pin# Signal Name
DCD 1 2 RXD
TXD 3 4 DTR
Ground 5 6 DSR
