Using the Optional Cap Frame 189
7
3
When sewing outlines of patterns, make sure
that the stitch width of the satin stitching is at
least 2 mm, and that the stitching over-laps
the fabric by at least 1 mm. Also, make sure
that there are no jumps of long stitches in the
outlining on each region or letter.
1 At least 1 mm
2 At least 2 mm
● Don’t sew more than four overlapping
layers.
1 Specify that overlapping areas not be sewn.
CAUTION
