Left Overlock Needle - O-1
1. Place the thread on the "OVERLOCK NEEDLE 1" spool pin. See fig. C, page 19. Bring the thread end
through the telescopic guide directly above the thread. Bring the thread through thread guide at top of
machine and down the "overlock needle I" thread path and in the guide just below the faceplate. Pull an 8
inch (20.5cm) length of thread through the guide. Follow the arrows as shown in the illustration. Thread the
guides above the needle.
2. Using the needle threader or tweezers, thread into the eye of O-1 needle.
Right Overlock Needle - O-2
1. Place the thread on the "OVERLOCK NEEDLE 2" spool pin. See fig. C, page 19. Bring the thread end
through the telescopic guide directly above the thread. Bring the thread through thread guide at top of
machine and down the "overlock needle 2 "thread path and in the guide just below the faceplate. Pull an 8
inch (20.5cm) length of thread through the guide. Follow the arrows as show in the illustration. Thread the
guides above the needle.
2. Using the needle threader or tweezers, thread the eye of O-2 needle.
Note: Make sure that each needle is set for overlock stitching; right needle is O-2 and left needle is O-1.
T
H
R
E
A
D
I
N
G
23
Overlock Needles
O1,O2
O1
O2
O1
O2
