MP-4000 TH POS Printer Rev.1.4 Programmer’s Manual
22-aug-2007
Firmware Release: 1.5 61
GS ( A p
L
p
H
n m
[Function] Execute test print.
[Format] ASCII GS ( A
p
L
p
H
n m
Hexadecimal 1D 28 41 p
L
p
H
n m
Decimal 29 40 65 p
L
p
H
n m
[Description] • Executes a test print with a specified test pattern on a specified
paper.
•
p
L
and p
H
specifies the number of the parameter such as n, m to (p
L
+ (p
H
× 256)) bytes.
• n specifies the paper to be tested:
n Paper
0, 48 Basic sheet (paper roll)
1, 49, 2, 50 Paper roll
m specifies a test pattern:
m Test pattern
1, 49 Hexadecimal dump
2, 50 Printer status print
3, 51 Rolling pattern print
[Details] (p
L
+ (p
H
× 256)) must be equal 2. Therefore, p
L
must be 2 and p
H
must be 0.
DLE DC4 n m t
[Function] Generate pulse at real-time.
[Format] ASCII DLE DC4 n m t
Hexadecimal 10 14 n m t
Decimal 16 20
n m t
[Description] Outputs the pulse specified by t to connector pin m as follows:
m Connector pin
0 Drawer kick-out connector pin 2.
1 Drawer kick-out connector pin 5.
[Details]
The pulse ON time is [t × 100 ms] and the OFF time is [t × 100 ms].
n
must be 1.
