BRONKHORST ®
Page 23 RS232 interface 9.17.027
6 3E Value 3E80h = 16000 = 50%
7 80
8 \r Carriage Return
End
9 \n Line Feed
Total String :06030201213E80\r\n
3.10.4 Request chained parameters
The Interface sends a request for the following parameters to module at node 3:
Process 113: Serial number (3), USERTAG (6)
Process 1: Measure (0), Capacity (13), Capacity unit (31), Fluid name (17)
Request chained parameters to node 3
Nr Byte Layout Description Description per block
0 :
Start
1 1A Length 26
2 03 Node 3
3 04 Command read
4 F1 11110001
C 80 Process chained (return)
Process 113 (return)
P 71 Process 113 (return)
5 EC 11101100
C 80 Parameter chained (return)
Parameter index 12 (return)
Process 113
Parameter number 3
Serial number
T 60 Parameter type ‘string’ (return)
N 0C Parameter index 12 (return)
6 71 01110001 P 71 Process 113
7 63 01100011
T 60 Parameter type ‘string’
P 03 Parameter number (FBnr.) 3 – Serial number
8 00 00000000 00 String length 00, length not defined
9 6D 01101101
C 00 Parameter not chained (return)
Parameter index 13 (return)
Process 113
Parameter number 6
USERTAG
T 60 Parameter type ‘string’ (return)
N 0D Parameter index 13 (return)
10 71 01110001 P 71 Process 113
11 66 01100110
T 60 Parameter type ‘string’
P 06 Parameter number (FBnr.) 6 – USERTAG
12 00 00000000 00 String length 00, length not defined
13 01 00000001
C 00 Parameter not chained (return)
Process 1 (return)
P 01 Process 1 (return)
14 AE 10101110
C 80 Parameter chained (return)
Parameter index 14 (return)
Process 1
Parameter number 0
Measure
T 20 Parameter type ‘integer’ (return)
N 0E Parameter index 14 (return)
15 01 00000001 P 00 Process 1
16 20 00100000
T 20 Parameter type ‘integer’
P 00 Parameter number (FBnr.) 0 – Measure
17 CF 11001111
C 80 Process chained (return)
Parameter index 15 (return)
Process 1
Parameter number 15
Capacity
T 40 Parameter type ‘float’ (return)
N 0F Parameter index 15 (return)
18 01 00000001 P 01 Process 1
19 4D 01001101
T 40 Parameter type ‘float’
P 0D Parameter number (FBnr.) 13 – Capacity
20 F0 11110000
C 80 Parameter chained (return) Parameter index 16 (return)
Process 1 T 60 Parameter type ‘string’ (return)
